Industrial Tablet UROVO i8000 v.5
|
|
The product from the archive - production terminated
|
Compare all versions
EQUIPMENT AVAILABLE FROM JANUARY 2014.
.jpg)
Shenzhen Urovo Technology Co., Ltd. is a leading manufacturer of software and hardware products and comprehensive provider of cross-industry information solutions. As one of the leading professional manufacturers of Mobile Handheld Data Terminal in China, we specialize in manufacturing and developing "All-in-one" handheld data terminal integrated with RFID reader/writer, 1D/2D barcode scanner and wireless communications.Based on application of mobile data terminal technology, Urovo has made a number of groundbreaking achievement.
|
|
.jpg)
UROVO's i8000 adopts ergonomic design for easy operation and supports outdoor visualization of screen display by fully taking into account the apllication environment of the customer while providing the properties of a special industry device. With IP54 rating, high-capacity, battery and extra-low power consumption, it is allowed to serve under harsh environment for a long time. It is designed for use in warehouse management, logistics, transportation management, e-commerce, law enforcement and other industrial areas.
|
System specifications
|
Processor |
Samsung Cortex-A8 S5PV210@1GHz |
|
Display |
7" TFT LCD (1240 x 600) capacitive : multi-touch |
|
RAM |
512MB |
|
ROM |
512MB |
|
Connectors |
USB host : mini USB : 3.5mm audio Jack |
|
|
option - Micro SD/TF: SIM : PSAM |
|
Audio |
Loudspeaker
|
|
Battery |
3.7V 3000mAh Lithium (over 8h of standby time) |
|
Keyboard |
numeric : alphabetic x12 / directional x4 / function x10 / scan button
|
|
Camera |
Front 1.3Mpx / Rear 5Mpx : autofocus
|
Operating System
|
Windows CE 6.0 R3 or Android 2.3 (multi-language) |
|
1D/2D Barcode Reader
Quick and accurate identification of the object crosses the warehouseman and does not create bottlenecks in logistics processes. 1D/2D Barcode Reader allows you to read, decode and send to your data stored in the bar code. With dynamic scanning capabilities and the large range of reading data collector Urovo i8000 carefully collected data, which helps to increase the rate and efficiency. The whole can jump-start, because with simplified installation and an intuitive, comfortable design to prepare the scanner to work is very easy.
|
Scanning rate: 100±20 scan/sec
|
|
1D Laser |
Code 39 : Codebar : Code 128 : Discrete 2 of 5 : IATA 2 of 5 : Interleaved 2 of 5 : Code 93 : UPC A : UPC E0 : EAN 8 : EAN 13 : MSI : EAN 128 : UPC E1 : Trioptic Code 39 : Bookland EAN : Coupon Code : RSS-Limited : RSS-14 : RSS-Expanded |
|
2D Laser |
1D Symbologies : UPC/EAN : Bookland EAN : UCC Coupon Code : ESSN EAN : CODE 39 : CODE 128 : GS1-128 : ISBT 128 : Trioptic Code 39 : CODABAR : MSI : Interleaved 2/5 : Discrete 2/5 : Chinese 2/5 : Korean 3/5 : Matrix 2/5 : CODE 32 : CODE 93: CODE 11 : Inverse 1D : GS1 DataBar : Composite Codes
|
|
|
2D Symbologies : PDF417 : MicroPDF417 : Data Matrix : Data Matrix Inverse : MaxiCode : QR Code : Aztec : Aztec Inverse Postal Codes: U.S. Postnet : U.S. Planet : U.K. Postal : Japan Postal : Australian Postal : Netherlands KIX Code : USPS 4CB/One Code/Intelligent Mail : UPU FICS Postal
|
|
Modules and Wireless Networks
|
WiFi |
802.11b/g
|
Frequency Range
|
54MB/sec, CISCO Compatible CCX2/3 Security, CISCO AP Security
|
|
Bluetooth |
Bluetooth Class2.1 with EDR
|
|
GPS |
Support A-GPS, 48 channels
|
Accuracy
|
<1m, 1sec wakeup, warm botuup less than 38sec |
|
WCDMA |
UMTS2100/900MHz : UMTS1900/850MHz : GSM850/900/1800/1900MHz |
|
GSM CS |
GSM CS: UL 9.6kbps/DL 9.6kbps
|
|
GPRS/EDGE |
Multi-slot Class12. Class B
|
|
WCDMA CS |
UL 64kbps/DL 64kbps
|
|
WCDMA PS |
UL 384kbps/DL 384kbps |
|
HSDPA |
DL 3.6Mbps
|
|
WAN |
GSM 850/900/1800/1900MHz
|
|
GPRS Class 10 |
Multi-slot, DL 85.6 kbps/UL 42.8kbps |
GPRS Class 8
|
Multi-slot, DL 85.6 kbps/UL 21.4kbps
|
CDMA 2000
|
CDMA 2000, DMA2000 EV-DO Rev 0, CDMA2000 EV-DO Rev A
|
|
Supports |
BC0 (800MHz band), BC1 (1900MHz band) |
CDMA 2000 1X
|
UL/DL: 153.6kbps
|
EVDO Rev.0
|
UL 153.6kbps DL 2.4Mbps
|
|
EVDO Rev.A |
UL 1.8Mbps DL 3.1Mbps |
go top...  menu…
|
|
|
|
i8000 is equipped with one USB / Mini USB, microSD card reader / PSAM / SIM card and audio output mini-jack. The possibility of recording enables integrated 5Mpx camera with autofocus. To facilitate the use of the device you will have a numeric keypad in addition alphabetical can define tasks for the selected the keys (hotkeys).
|
Dimensions |
240x130x20mm
|
|
Weight |
450g (including battery)
|
.jpg)
go top... menu…
|
|
|
|
Operating |
-10°C -- +50°C |
|
Storage |
-20°C -- +60°C |
|
Humidity |
5% -- 95% non condensing
|
Dust protection
|
IP5x (dust) |
Water protection
|
IPx4 (water) |
|
Drop |
multiple drops to concrete: 1.2m across the operating temperature range |
|
Regulatory |
CCC / CE / FCC |
Electrical Safety
|
Certified to Ul60950, CSA C22.2 No.6050, EN60950/IEC950
|
Laser Safety
|
IEC Class 2/FDA Class II, in accordance with IEC60825/EN60825-1
|
go top... menu…
Resistance IP54
IP Degrees is a classification of different levels of protection of electrical equipment That Are provided by enclosures of these devices According to PN-92/E-08106. A number after the "IP" is really two digits. The first is protection of human and animal access to hazardous parts and protection against contaminants, dry as dust. The second digit is a degree of protection against water.
go top... menu…
|
The first digit [x]
Protection against solid objects |
|
The second digits [y]
Protection against liquids |
|
No special protection |
|
0 |
 |
0
|
|
No waterproofing |
|
Protection from solid objects greater than 50mm in diameter |
|
1 |
 |
1
|
|
Protection from dripping water
|
|
Protection from object not greater than 12mm in diamete |
|
2 |
 |
2
|
|
Protection from vertically dripping water (tilted up to 15°) |
|
Protection from object not greater than 2,5mm in diameter |
|
3 |
 |
3
|
|
Protection from sprayed water (tilted up to 60°) |
|
Protection from object not greater than 1mm in diameter |
|
4 |
 |
4
|
|
Protection from splashed water |
|
Complete protection against contact, Protection against dust deposit |
|
5 |
 |
5
|
|
Protection from water projected from a nozzle |
|
Complete protectionm against contact, Protection from infiltration of dust |
|
6 |
 |
6
|
|
Protection against heavy seas, or powerful jets of water |
|
|
|
 |
7
|
|
Protection against immersion
|
|
|
|
.gif) |
8
|
|
|
Protection against complete, continuous submersion in water
|
|
Hardware configuration
If none of the available configuration does not interest you, you can always suggest your option components. Submit your suggestion using the contact form - up to 2 working days you will receive a valuation of the desired configuration. Remember to carefully specify each parameter and accessories.
|
 |
|
Compare all versions
| Durability: |
IP54 |
| Humidity: |
5% -- 95% non condensing |
| Waterproof: |
IP54 |
| Weight: |
|
| Temperature: |
Operating (-10°C -- +50°C) / Storage (-20°C -- +60°C) |
| Shock: |
----- |
| Vibration: |
----- |
| Drop: |
multiple drops to concrete: 1.2m across the operating temperature range |
| Sand and dust: |
IP54 |
| 1D barcode scanner (reader): |
Yes - (Motorola Scan Engine)
Code 39 : Codebar : Code 128 : Discrete 2 of 5 : IATA 2 of 5 : Interleaved 2 of 5 : Code 93 : UPC A : UPC E0 : EAN 8 : EAN 13 : MSI : EAN 128 : UPC E1 : Trioptic Code 39 : Bookland EAN : Coupon Code : RSS-Limited : RSS-14 : RSS-Expanded |
| 2D barcode scanner (reader): |
none (available in other configurations) |
| RFID scanner (reader): |
No |
| Magnetic card reader (MSR): |
No |
| Microchip card reader: |
No |
| Docking station connector: |
No |
| VESA standard – holders and mounts support: |
No |
| COM port: |
No |
| Dispaly: |
7" TFT LCD (1240 x 600) capacitive : multi-touch |
| Brightness: |
----- |
| Contrast: |
----- |
| Touch screen: |
Yes - Capacitive multi-touch |
| Graphics card: |
----- |
| Swivel Hinge: |
No |
| VGA out: |
----- |
| TV Out: |
----- |
| TV Tuner: |
No |
| Processor: |
Samsung Cortex-A8 S5PV210@1GHz |
| Chipset: |
----- |
| BIOS: |
----- |
| Memory: |
512MB RAM / 512MB ROM |
| Hard Drive: |
512MB + SD Card (possible to mount the sd card max.32GB) |
| Flash Memory: |
|
| Battery: |
3.7V 3000mAh Lithium |
| Working time on battery: |
6 - 8h |
| HotSwap battery: |
No |
| Fast battery replacement ability: |
No |
| Size: |
240x130x20mm - 450g (including battery) |
| Casing material: |
----- |
| Fanless casing: |
Yes |
| Operating System: |
Android 2.3 (multi-language) or Windows CE 6.0 R3 |
| LAN: |
No |
| WLAN: |
Yes - 802.11b/g (54MB/sec, CISCO Compatible CCX2/3 Security, CISCO AP Security) |
| Bluetooth: |
Yes- Bluetooth Class2.1 with EDR |
| WAN: |
none (available in other configurations) |
| GPS: |
none (available in other configurations) |
| Flash Card Reader: |
----- |
| CD/DVD: |
----- |
| Camera: |
Yes - Front 2Mpx / Rear 5Mpx |
| Audio: |
Loudspeaker / 3.5mm Jack |
| Seciurity: |
----- |
| In/Out: |
Micro SD/TF : SIM : PSAM : USB host : mini USB : 3.5mm audio jack |
| Keyboard: |
numeric : alphabetic x12 / directional x4 / function x10 / scan button |
| Additional Navigation Devices : |
----- |
| Color: |
czarny |
| Optional accessories: |
----- |
| Other: |
----- |
Compare all versions
